K1123 Kipp UNI lock manual clamping module
View product information as a PDF datasheet:
Product Specification Datasheet for K1123 Kipp UNI lock manual clamping module
Product Specification Datasheet for K1123 Kipp UNI lock manual clamping module
Material:
Steel.
Version:
Contact faces case-hardened and ground.
Note:
UNI lock manual clamping modules can be adapted directly to machine tables with grid holes or T-slots, and to grid hole subplates with 50 mm grid spacing system size M10/M12/M16.
The UNI lock manual clamping module H 50 is particularly suitable for machines with reduced Z travel. The low installation height of the manual clamping module facilitates full utilisation of the Z travel.
The UNI lock manual clamping module H 50 can be mounted in any position.
Supplied with:
1 manual clamping module incl. fastening accessories.
Technical data:
Repeat accuracy ≤ 0.005 mm
Special features:
Order No. K1123.1605050
