K0255 Kipp Five lobe grips
Here is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table in the datasheet.
Product description: This newly developed design eases operating and clamping processes. Completely new freedom of applications and the associated creativity contribute towards harmonizing human requirements and the stipulated grip safety.
Version: Steel trivalent blue passivated, stainless steel bright.
Note: The screw lengths 15, 35 and 45 are not available in stainless steel.
