Norelem 21104 Positioning stages, short with electronic position indicator
Product Specification Datasheet for Norelem 21104 Positioning stages, short with electronic position indicatorView CAD Files
Modular positioning system with an electronic position indicator. Electronic position indicator with 0.01 mm display accuracy and large LCD display. Reset, chain dimension and offset settings can be made via the keypad.
- 2 years battery life. The battery is quick and easy to replace.
- The mounting position of the position indicator is set in 4 positions using one screw.
- The modular design enables the positioning stage to be easily combined with other items of the same size.
Due to the practically play-free guides and absolutely play-free spindle, loosening or clamping of the spindle is not required during adjustments.
- Radial play on guide < 0.02 mm.
- No axial backlash.
- Spindle self-locking, with additional lock.
- Material: Bearing block and carriage aluminium alloy, anodised. Guide columns stainless steel, ground. Spindle stainless steel, rolled thread. Guide bearing maintenance-free. Position indicator plastic.
Order No: 21104-08 21104-12
