Norelem 21142 Vertical stages with electronic position indicator

For height-positioning of components and assemblies of all types (e.g. stops, sensors, limit switches, tables, cameras, entire assemblies, etc.). Electronic position indicator with 0.01 mm display accuracy and large LCD display. Reset, chain dimension and offset settings can be made via the keypad. 2 years battery life. The battery is quick and easy to replace.

The mounting position of the position indicator is set in 4 positions using one screw. The modular design enables the vertical stage to be easily combined with positioning
stages, cross slides and other accessories of the same size.

  • Material:
    Bearing block and carriage aluminium alloy, anodised.
    Guide columns stainless steel, ground.
    Spindle stainless steel, rolled thread.
    Guide bearing maintenance-free.
    Position indicator plastic.
  • Version:
    Guide backlash < 0.05 mm.
    Spindle self-locking, with additional lock.

Order No: 21142-08 21142-12 21142-25
